How To Adjust The Operating Energy Parameters of The Fractional CO2 Laser Machine

The Fractional CO2 laser machine has three modes (fractional, cutting, and private), which are multifunctional to meet various treatment needs. Different modes require different adjusted parameters. Below I will provide you with some suggestions on adjusting the energy parameters when using the co2 laser machine.

Fractional mode:

(select fractional handpiece)

①     Select the scanning pattern and area size suitable for the treatment area

②     In the scanning mode interface, you can choose random or centered, so that the thermal damage is small

③     Pulse width:

• Select 0.2-1ms for superficial skin grinding

• 3-10ms for hyperplastic or depressed scars

④     Energy:

• 4-8w for smooth skin and normal pores

• 4-6w for chloasma and pigmentation

• 8-14w for acne pits and enlarged pores

Cutting mode:

(select cutting handpiece)

①    Select the corresponding mode according to different lesions (continuous mode, pulse mode, super pulse mode, long pulse mode)

②    Energy:

• Small facial tumors (moles, warts) :10-30w

• Other parts of the body (thicker skin) :30-70w

(The growth becomes smaller and flatter, indicating that the energy is appropriate, until it is level with normal tissue or slightly protrudes)

Private mode:

(select private handpiece)

①   Select the maximum energy, and the handpiece enters the vagina for operation

②   Operate clockwise, rotate 35° each time, and each time rotate one circle then move 2cm outward, and continue to rotate until the vaginal opening (the energy should gradually decrease as you go out)

Others:

• Key points for hyperplastic lesions:

At the beginning of treatment, it is necessary to ensure that the treatment head is in close contact with the skin and vertically aligned with the lesion site for treatment. The core principle of treatment is to completely remove benign hyperplastic lesion tissue, and the root of the lesion must be completely removed so that the surface growth is flush with the skin surface. At the same time, damage to normal tissue should be minimized to avoid excessive inflammatory response.

• Key points for fractional mode operation:

The galvanometer needs to be vertically and closely attached to the skin. If the patient has a hormone face, the medical history must be asked in detail before treatment. It is strictly forbidden to carry out the operation blindly, and it is forbidden to operate during the outbreak of hormone face. For customers with sensitive skin, the energy needs to be adjusted to a lower level.

• Key points for private mode operation:

The hand tool should be kept in a vertical downward direction, close to the skin first, and then the foot pedal should be pressed. After completing the dotting operation, release the foot pedal, and pay attention to the fact that the light spots cannot overlap.
