To meet diverse clinical needs, the device features two intelligent operating modes:
✅Fractional Mode (Spot Treatment)
Designed for deep penetration and focused energy delivery. The laser creates Micro-Thermal Zones (MTZs) while preserving surrounding tissue integrity, ensuring significant lifting, tightening, and elastin regeneration.
✅Scanning Mode (Sliding Operation)
An efficient solution for full-face rejuvenation. Continuous sliding allows for a full-face treatment in just 6–8 minutes, significantly increasing patient throughput for the clinic.
To support these operating modes, Newangie's 1927nm Thulium laser skin rejuvenation system is equipped with two corresponding handpieces: a fractional handpiece and a scanning handpiece.
Fractional Mode: The laser beam is split into hundreds of tiny beams by a special optical system (such as a microlens array), creating a series of microscopic treatment zones (MTZs) on the skin while ensuring the surrounding skin remains intact.
Precise Firing: During treatment, the treatment head typically maintains perpendicular contact with the skin and remains stationary, firing once, moving slightly to cover the next area.
Extensive Adjustable Parameters: Energy density, treatment pattern, and spot size can usually be precisely adjusted, offering high flexibility and enabling personalized treatment.
Deeper Penetration: More concentrated energy effectively penetrates the dermis, resulting in a more pronounced effect on stimulating collagen and elastin regeneration.
Scanning Mode: The laser beam scans an area continuously, rapidly, and uniformly.
Sliding Operation: The treatment head can slide smoothly and continuously along the skin surface, providing very fast treatment speed and highly efficient coverage of large areas.
Parameter Presets: Energy and scanning speed are usually linked and controlled by the device's built-in intelligent program to ensure uniform energy output and safety during high-speed sliding, simplifying operation.
Superficial Depth of Action: Energy is more evenly distributed in the epidermis and the superficial layers of the dermis, resulting in gentler and more superficial thermal stimulation.
| Feature | 1927nm Thulium Laser | CO2 Fractional Laser (10600nm) |
|---|---|---|
| Primary Target | Water (Epidermis/Upper Dermis) | Water (Deep Dermis/Ablative) |
| Downtime | Minimal (1-3 days redness) | Significant (7-14 days crusting) |
| Pain Level | Low (Comfortable without numbing) | High (Requires topical anesthesia) |
| Risk of PIH | Extremely Low | Higher on darker skin types |
| Best For | Pigmentation, Brightening, Fine Lines | Deep Scars, Severe Wrinkles |
Machine Type | 1927nm Thulium Laser |
Wavelength | 1927nm |
Laser Power | 30W |
Energy | 1-300mJ |
Working Mode | Fractional, Pulse, Super Pulse |
Tip Size | 30mm |
Pulse Width | 0.1-10ms |
Graphic Size | 1x1mm-20x20mm |
Scan Mode | Order, Center or Random |
Scan Graphic | Rectangle, Square, Triangle, Round, Elipse, Hexagon |
Spot Distance | 0.1-2mm |
Cooling System | Air Cooling |
Looking to upgrade your clinic with the latest laser technology? As a professional manufacturer, Newangie provides high-quality devices with CE certification and global shipping.
